| 投影機類型 | UXGA 3-chip DLP digital projector |
|---|---|
| 技術 | 0.96" DMD™ x3 |
| 分辨率 | 1,600 x 1,200 |
| 亮度 | 30,000 center lumens* |
| 對比度 | 2,000:1 |
| 亮度均勻性 | 90% |
| 縱橫比 | 4:3 |
| ScenergiX | Horizontal and vertical edge blending |
| 鏡頭 | TLD+ 0.73:1 ; 1.2:1 ; 0.8-1.16 ; 1.25-1.6:1 ; 1.5-2.0:1 ; 2.0-2.8:1 ; 2.8-4.5:1 ; 4.5-7.5:1 ; 7.5-11.5:1 |
| 光學鏡片移動 | V: -100% to +130% / H: +/- 40% on zoom lenses (memorized) |
| 色彩糾正 | P7 |
| 光源 | laser phosphor with inorganic phosphor wheel |
| 光源使用期限 | +20,000 hrs |
| 擋光板 | Standard |
| 畫中畫 | Two sources simultaneously |
| 封裝DLP™內核 | standard |
| 定位 | 360° |
| DMX 512 | standard |
| WARP | Direct adjust OSD + toolset |
| 集成網絡服務器 | Yes |
| CLO（穩定光輸出） | Standard |
| 3D | Active eye wear (optional), passive circular (optional); 3 flash up to 200Hz |
| 輸出 | Dual HDBt; HDMI 2.0 (HDCP 2.2); DP 1.2 (HDCP 1.3); Quad SDI/HDSDI/dual HDSDI/6G/BarcoLink |
| 可選輸入 | Quad DP1.2 |
| 輸入分辨率 | From NTSC up to 4K (4,096 x 2,160) |
| 最大像素時鐘 | 600 MHz |
| 軟件工具 | Projector Toolset + Android app + iOS app |
| 控制 | XLR wired + IR, RS232, Wifi, GSM (opt) |
| 網絡連接 | 10/100 base-T, RJ-45 connection, Wifi (optional) |
| 電力要求 | 120-160V / 200-240V (+/- 10%), 20A, 50-60Hz |
| 最大功耗 | 2,900W nom/3,100W max / STBY less than 10W |
| 噪音級別（典型，25°C/77°F時） | 52dB(A) |
| 操作環境溫度 | 0-40°C / 32°-104°F |
| 操作濕度 | 0-80% (non condens) |
| 消散 BTU | Max. 10,921 BTU/h |
| 尺寸(寬x長x高) | 660 x 830 x 350 mm / 25.98 x 32.7 x 13.78 inches |
| 裝運尺寸 | (LxWxH) 1,200 x 800 x 685 mm / 47.24 x 31.49 x 26.96 inches |
| 凈重 | 92kg (202 lbs)/shipping weight from factory: 110kg (242lbs) |
| 標準配件 | Power cord, wireless/XLR wired rugged remote control, bottom rigging kit/clamps |
| 證書 | Compliant with UL60950-1 and EN60950-1, complies with FCC rules & regulations, part 15 Class A and CE EN55032 Class A, Rohs |
| 保修期 | 3 years |
| * | +/- 10% |
